Plans & Kits

9 foot wooden catamaran

ZEN is a very simple 10 Foot boat (www.diecipiedi.it) particularly narrow and therefore unstable. It is not the right boat for a beginner but, in the hands of a good helmsman, it may be fast.

A 35' centerboard cruising boat designed for long-distance cruising and living aboard. Simplicity’s raised deck and 11’ beam result in a spacious interior, with standing headroom throughout. Construction is plywood over plywood bulkheads and frames.

The AC 75 Evolution design input was to crate a trailerable boat with a small displacement, building with traditional materials such as wood. Another request was to have a comfort and an interior volume typical of larger size boats. We have modified the deck lines to achieve these results.

Cutter designed by John Hyslop in 1876. An early combination of English and American ideas, PETREL was designed according to the wave form theory.You’ll receive 2 pages of plans historical information about the boat and step-by-step instructions for half-hull building,using the lift method.The pl

Designed as a cat schooner; both sails have big round poles at their leading edges. Considering the performance potential of this hull, this rig is appropriate. The stayless rig is clean and will be cheap to build with solid fir poles.

Cape Cutter 19 lapstrake plywood trailer-sailer

ROBERTS 19 TRAILERABLE The SUPER STUDY PLAN PACKAGE has details of all of the construction techniques and includes materials lists, and accommodation layouts for both trunk cabin or motor sailer versi

A most elegant lapstrake, plywood peapod for oar and sail.

Full-sized mold patterns are included.

Construction: Glued-lapstrake plywood.

Alternative construction: Traditional lapstrake.

No lofting is required.

Sharpie 31.5′ EGRETL.O.A.: 31′ 6 ½″SPARRED LENGTH: 35′ 6″L.W.L.: 26′ 3″BEAM: 8′ 6″DRAFT: 1′ 2 ¼″ /4′ 8″SAIL AREA : (Depends on rig)DISP.: 5,000# (approximate, for cruising)BALLAST: 1,500 lbs. lead, inside; additional to trim as needed.
