START 80


Category: Racing Sailboats

This boat, with a LOA of 8 mt,develops an internal volume such as to allow 6 crew members a sailing cruise.

The hull lines and deck lines are to corner for simplicity of construction, and are harmonized with the hull volume. The interior with a height of 1.85 mt, offers hospitality to 6 crew members.

There are double berth in the fore and aft and two singles in the dinette.

The chemical toilet is on the starboard of the dinette and the kitchen is in front of the toilet.



DESIGN SPECS
Designer:
ACDesign
LOA:
8.01 mt
Beam Length:
2.94 mt
Draft Length:
1.80 mt
LWL:
7.45 mt
Displacement:
Empty 1700 kg / Full 2155 kg
Materials:
Wood
Propulsion:
InB 9 Hp
Skill Level to Build:
intermediate
Available as:
Kit & Complete Plans
Website:
Contact Information:

ACDesign
Via Don Filippo Bassi,19 - 25075 Nave (BS) - ITALY

www.acdesigngroup.net
info@acdesigngroup.net

Tel: +39 (0)30 2534641
Fax:+39 (0)30 2534641
P.Iva 03541660175
