7.5m Racing Tri built in ply

This 16' x 21" [4.9m x 53cm] strip planked kayak is adapted to comfort and responsiveness in active water. The nearly plumb bow and stern provide a long waterline in a compact package, allowing a good turn of speed in manageable size.

Sharpie 31.5′ EGRETL.O.A.: 31′ 6 ½″SPARRED LENGTH: 35′ 6″L.W.L.: 26′ 3″BEAM: 8′ 6″DRAFT: 1′ 2 ¼″ /4′ 8″SAIL AREA : (Depends on rig)DISP.: 5,000# (approximate, for cruising)BALLAST: 1,500 lbs. lead, inside; additional to trim as needed.

Based loosely on the Folkboat, this plywood lapstrake double-ender combines comforting rough-water ability, and good looks.

Construction: Lapstrake plywood over laminated frames.

Alternative construction: Traditional plank on frame, strip or cold-molded.

The SAMPAN 36 HOUSEBOAT is a simple, pragmatic floating home suitable for a couple with a child. It is self-contained and intended for use in a marina or at anchor. It may employ an outboard motor, or simply be towed to a semi-permanent mooring.

Bow and stern of English traditional narrowboat. Cutting files to produce a kit of steel parts for assembly. The midsection is a parralel box that can vary between 20 and 40ft. The midsection is produced by folding steel plate then adding the bow and stern.

Construction - Glued lapstrake plywood.

Alternative construction - Traditional, cold-molded and strip plank.

No Lofting required.

Plans include 8 sheets.

Sail Area - Lug 87 sq. ft.

Sloop 104 sq. ft.

Yawl 121 sq. ft.

SF Pelican 12 foot: Three sheets of drawings, step-by-step building instructions, sail plans, lists for materials and hardware, and sailing handling information.
Note: Drawing plans come in pdf format and can be printed to full hard copy format.

My first boat building Project (not counting a couple of door-skin surfboards) was a Bolger Yellow Leaf pirogue, built from drawings in Bolger’s “Small Boats”.

This boat has a comfortable feel to it and a stability that makes kayaking in any weather comfortable.
